Multilayer Flex Rigid PCB Polyimide/PI+FR4 Material PCB Board China PCB Fabrication

Name: Multilayer Flex Rigid PCB PolyimidePIFR4 Material PCB Board China PCB Fabrication
Brand: ABIS
Price: 1 USD

China Multilayer Flex Rigid PCB Polyimide/PI+FR4 Material PCB Board China PCB Fabrication wholesale

Brand Name : ABIS

Model Number : PCB-M58

Certification : ISO14001, ISO9001, UL, cUL, TS16949

Place of Origin : Made in China

MOQ : 1

Price : Customized

Payment Terms : T/T, Western Union, paypal ect.

Supply Ability : 60,000sqm per month

Delivery Time : 1-15 working days

Packaging Details : Vacuum package

Board thickness : 0.2-6.0mm

Layer : 1-8 Layers

Copper thickness : 1/2OZ 1OZ 2OZ 3OZ,1/3oz ~6oz

Min. line width : 3mi,0.075mm

Base material : FR-4,CEM3,CEM-1,TACONIC,FR-4/High TG

Solder mask color : White or as your request

Surface finishing : HASL, HASL-LF,ENIG,OSP,Immersion Gold,

Product name : Printed Circuit Board,Flex-Rigid PCB,Assembly for Circuit Board

Application : Consumer Electronics,Electronic products,Industry/Medical/Consumer electronic,

Type : Electronic Board,Customizable,Pcb design,electronic pcb

Contact Now

Multilayer Flex Rigid PCB Polyimide/PI+FR4 Material PCB Board China PCB Fabrication

Abis Circuits Co., Ltd is a professional PCB manufacturer which was established in Oct 2006 and focuses on double side, Multilayer, and HDI PCB production.

Our Mission:

PCBs for demanding customers, on time with zero defects, are produced sustainably at the lowest total cost. Manufacturing many different types of PCBs in smaller series (High-mix, Low-volume) involves constantly adjusting, adapting, and problem-solving.

Rigid PCB Capacity:

Max. No. of Layers	20
Max. Board Size	860*610mm
Board Thickness	0.2-6.0mm
Copper Thickness	0.5OZ-6OZ
Material	Various
Surface Finish	Various
Soldermask	Various
Minimum Soldermask Thickness	0.025mm
Minimun Soldermask BridgeDam	0.15mm
Minimum Soldermask Clearance	0.075mm
Peelable Colours	Blue
Peelable Minimum Feature	0.5mm
Peelable Maximum Tented Hole	3.0mm
Scoring Angle	30 Degrees
Min. Remaining Thickness	0.3mm
Min. Distance to copper (From the center of the scoring line)	0.5mm
Min. Track	0.1mm
Min.Gap(TrackTrack,TrackPad,PadPad)	0.1mm
NPTH Min. Drill Size	0.2mm
Plated Drill Size	± 0.075mm
Non-Plated Drill Size	± 0.05mm
Drill Location Tolerance	± 0.05mm
OutlineRouted Slots	± 0.1mm
Line Width/Spacing	±10%
Board Thickness	±10%
Warp and Twist	0.05%
Scoring/V-Cut	± 5 degrees
Scoring Positional Tolerance	± 0.1mm
Aspect Ratio	10:01

Flex PCB Capacity:

Number of layers	1 – 8L
Technology highlights	Mainly polyimide materials, flex PCBs are necessary when the motion of the PCB is needed, when 3-D interconnections are necessary (i.e. replacing cables and connectors), or when these are both combined due to limited available space.
Materials	Polyimide, Polyester
Profile method	Laser cutting, punching, rout
Copper weights (finished)	18μm – 70μm
Minimum track and gap	0.075mm / 0.075mm
PCB thickness	0.05mm – 0.80mm
Maxmimum dimensions	450mm x 610mm
Surface finishes available	OSP, ENIG, Immersion tin, Electrolytic gold, Gold fingers
Minimum mechanical drill	0.15mm

Workshop:

Exhibition show:

Multilayer Flex Rigid PCB Polyimide/PI+FR4 Material PCB Board China PCB Fabrication

Shipping Method and Payment terms:

1. By DHL, UPS, FedEx, and TNT using clients' accounts.

2. We suggest you use our DHL, UPS, FedEx, and TNT forwarder.

3. By EMS (Usually for Russia Clients), the price is high.

4. By sea for mass quantity according to customer's requirement.

5. By customer's Forwarder

6. By Paypal, T/T, West Union, etc.
